Hydraulic test benches
Hot water/cold water loop

Reference : WaterLoop
Areas of application :
Request a quote

Technical description

The EC/EF loop is used as a heating and cooling source for the internal regulation of the benches

Main functions

This autonomous system ensures the regulation of the temperatures of a heating loop and a cooling loop used as heating and cooling sources for hydraulic test benches.

Operating mode

The system ensures the circulation of water in the hot loop and the cold loop by servo pumps. Cooling is ensured by a cooling unit, the heating is ensured by electrical resistances regulated on PT100 sensors.



Characteristics

WaterLoop-10 WaterLoop-15 WaterLoop-20

Heating power
10 kW 15 kW 20 kW

Cooling power
10 kW 15 kW 20 kW

Power supply - three phase + neutral + earth
380VAC - 40 A 380VAC - 40 A 380VAC - 40 A

Automatic filling

Temperature control



Width
≈ 1 250 mm
Height
≈ 1 300 mm
Depth
≈ 1 850 mm
Weight
≈ 650 kg

Advantages

Coupled with the temperature control system by internal vessels of the LF Technologies test benches, this economical equipment allows the use of the bench in a thermal regulation closed circuit system with high precision.




Ihm

Human-computer interface
